3M ™ Multimedia Projector MP8740 © 3M 1999
ENGLISH
4.3 SETUP
The SETUP sub-menu is used to adjust and move the image position. The projector will display either the RGB
(Figure 4.4) or Video (Figure 4.5) menu according to the input source being projected.
RGB signal input Video signal input
✔ Note
• TINT cannot be adjusted with a PAL or M-PAL video signal input.
• TINT, COLOR and SHARPNESS cannot be adjusted with an RGB signal input.
• V. POSIT, H. POSIT, H. PHASE and H. SIZE cannot be adjusted with a VIDEO signal input.
10
Adjustment Item
VOLUME
BRIGHT
(BRIGHTNESS)
CONTRAST
SHARPNESS
COLOR
TINT
V.POSIT
(V.POSITION)
H.POSIT
(H.POSITION)
H.PHASE
H.SIZE
COLOR BAL
Details of adjustment
Decrease Increase
Dark Bright
Lower Higher
Soft Sharp
Less More
Red Green
Moves the picture up or down.
Moves the picture left or right.
Decreases the picture flicker
Widens or Narrows the horizontal size of picture
Red Blue
Default
Figure 4.4 RGB Signal Figure 4.5 Video Signal
