Section 1: Unpack
1.1 Contents of Shipping Box
The 3M ™ MP8780 Multimedia Projector is shipped with the necessary cables required for standard VCR, PC, MAC ™ II or
laptop computer connections. Carefully unpack and verify that you have all of the items shown below in Figure 1.1. If any
of these items are missing, please contact your place of purchase.
Figure 1.1 Inventory of Shipping Box
1.2 Optional Accessories
• RS-232 control cable .................................................... (1)
• Gender Change SVGA MAC Monitor Adaptor ........... (1)
• USB mouse cable .......................................................... (1)
1.3 Keep Your Packing Materials
✔ Important
Save the shipping box and packing materials in the event the MP8780 should require shipping to a 3M Service
Center for repair.
1.4 What's Next?
After you have unpacked the MP8780 system and identified all the parts, you are ready to set up the projector.
We hope you will enjoy using this high performance product in your meetings, presentations and training sessions.
This product has been produced in accordance with 3M's highest quality and safety standards to ensure smooth and trouble
free use in the years to come.
