3M MP8780 User Manual
Page 24
© 3M 1999 3M
™
Multimedia Projector MP8780
TECHNICAL
A-1
Product name
Model Name
Display system
Panel size
Drive system
Number of pixels
Lens
Lamp
Speaker (stereo)
Power supply
Power consumption
Operating temperature range
Dimensions
Weight
video signal input
terminal
RGB input/output
signal terminal
Control terminal
Mouse MD 9pin (serial/PS2/ADB)
USB 4pin
Appendix: Technical Information
Table of Contents
A.3 Projector-to-Screen Distance
A.4 Connection to the Video Signal Terminal
A.5 Connection to the RGB Signal Terminal
A.7 Connection to the Control Signal Terminal
A.1 Technical Specifications
✔ Note
All specifications are subject to change without notice.
Multimedia projector
MP8780
3 LCD panels, strip pixel configuration.
46 mm (1.8 in.)
TFT active matrix
786,432 pixels (V768
×
H1024) per panel. 2.36 million total pixels with 3 panels.
F/Number: F/2.7 – F/3.4 Focal Length: F = 72 – 108 mm (2.8 in. – 4.3 in.)
Metal Halide lamp 440W
2 x 3 watt
AC100
∼
240V, 6.5A ~ 2.9A, 50/60 Hz (Automatic)
630W typical
32
°
∼
95
°
F (0
°
~ 35
°
C)
17.2 in. (W) x 8.9 in. (H) x 19.8 in. (D)
430 mm (W) x 222 mm (H) x 495 mm (D)
16.0 kg (35 lbs.)
S VIDEO : Mini DIN 4pin terminal
VIDEO : RCA Jack termina + BNC
AUDIO : RCA Jack terminal
RGB signal : D-sub 15pin (Female)
AUDIO : RCA Jack + BNC
D-sub 9pin (Male)
Liquid crystal
panel
Input/Output
terminal
