© 3M 1999 3M ™ Multimedia Projector MP8780
TECHNICAL
A-5
c) Example of computer signal
Scan Frequency
Dot Clock
Mode No. H-Size Resolution H (kHz) V (Hz) (MHz) Computer
1 780 320x480i 15.7 59.9 12.270 NTSC(RGB) RGB-NTSC
2 940 384x576i 15.6 50.0 14.687 PAL(RGB) RGB-PAL
3 848 640x400 24.8 56.4 21.053 640X400 TEXT56
4 900 720x400 31.5 70.1 28.322 720X400 TEXT70
4 800 640x400 31.5 70.1 25.175 720X400 TEXT70
4 800 640x350 31.5 70.1 25.175 720X400 TEXT70
5 936 720x400 37.9 85.0 35.500 720X400 TEXT85
5 832 640x400 37.9 85.1 31.500 720X400 TEXT85
5 832 640x350 37.9 85.1 31.500 720X400 TEXT85
6 800 640x480 31.5 59.9 25.175 640X480 VGA60
7 896 640x480 35.0 66.6 31.334 MAC13 MAC13
8 832 640x480 37.9 72.8 31.500 640X480 VGA72
9 840 640x480 37.5 75.0 31.500 640X480 VGA75
10 832 640x480 43.3 85.0 36.000 640X480 VGA85
11 1024 800x600 35.2 56.3 36.000 800X600 SVGA56
12 1056 800x600 37.9 60.3 40.000 800X600 SVGA60
13 1040 800x600 48.1 72.2 50.000 800X600 SVGA72
14 1056 800x600 46.9 75.0 49.500 800X600 SVGA75
15 1048 800x600 53.7 85.1 56.250 800X600 SVGA85
16 1152 832x624 49.7 74.6 57.283 MAC16 MAC16
17 1344 1024x768 48.4 60.0 65.000 1024X768 XGA60
18 1328 1024x768 56.5 70.1 75.000 1024X768 XGA70
19 1312 1024x768 60.0 75.0 78.750 1024X768 XGA75
20 1376 1024x768 68.7 85.0 94.500 1024X768 XGA85
21 1312 1024x768 48.8 60.0 64.000 MAC19A MAC19A
22 1328 1024x768 60.2 74.9 80.000 MAC19B MAC19B
23 1264 1024x768i 35.5 87.0 44.900 1024X768I XGAi
24 1472 1152x864 54.1 60.1 79.648 1152X864
25 1472 1152x864 64.0 70.0 94.178 1152X864
26 1600 1152x864 67.5 75.0 108.000 1152X864
27 1568 1152x864 77.3 84.9 121.268 1152X864
28 1456 1152x870 68.6 75.0 99.931 MAC21 MAC21
29 1500 1152x900 61.8 66.0 92.707 1152X900 SUN
30 1800 1280x960 60.0 60.0 108.000 1280X960
31 1680 1280x960 75.0 75.0 126.000 1280X960
32 1728 1280x960 85.9 85.0 148.500 1280X960
33 1688 1280x1024 64.0 60.0 108.000 1280X1024 SXGA60
34 1688 1280x1024 80.0 75.0 135.000 1280X1024 SXGA75
35 1728 1280x1024 91.1 85.0 157.500 1280X1024 SXGA85
36 1688 1280x1024i 47.7 88.8 80.534 1280X1024I SXGAi
37 2160 1600x1200 75.0 60.0 162.000 1600X1200 UXGA60
38 2160 1600x1200 81.3 65.0 175.500 1600X1200 UXGA65
39 2200 1920x1080i 33.7 59.9 74.176 HDTV1080I HDTV1080
39 1100 960x1034i 33.5 59.0 36.851 HDTV1080I HDTV1034
40 1650 1280x720 45.0 59.9 74.176 HDTV720P HDTV720P
41 2200 1920x1080 67.4 59.9 148.352 HDTV1080P HDTV1080P
