Prestige 304 Broadband Sharing Gateway with 4-Port Switch
4
WAN 10M Port
Connect the WAN port on the Prestige to the Ethernet port on the cable or xDSL
modem using the Ethernet cable that came with your modem. The Ethernet port
on a cable modem is sometimes labeled "PC" or "Workstation".
LAN 10/100M Ports
When the Prestige is on and properly connected to a
computer or a hub, the corresponding LAN LED on the
front panel turns on.
For more than four computers, use an external hub.
LAN 10/100M
PORT NUMBER
TYPE OF ETHERNET CABLE FOR CONNECTING THE
PRESTIGETO A …
COMPUTER HUB
1 straight-through crossover
2 straight-through crossover
3 straight-through crossover
4 UPLINK button
“on” (pushed in) straight-through crossover
4 UPLINK button
“off” (out) crossover straight-through
POWER 5VDC Port
Use only the included 5 VDC power adapter or one with the
same specifications.
Connect the female end of the power adapter to the port labeled POWER
5VDC on the rear panel of your Prestige.
Additional Installation Requirements
1. A computer(s) with an installed Ethernet NIC (Network Interface Card).
2. A cable/xDSL modem and an ISP account.
