ZyXEL Communications 802.11g High Power Wireless Router P-334WH - Manual (Page 11)

ENGLISH
11
Ethernet Connection
A Select Ethernet as your WAN connection type.
B Select Get automatically from your ISP if your ISP did not assign you a fixed IP address. Skip to C.
Or
Select Use fixed IP address provided by your ISP to give the P-334WH a static IP address. Go to B1.
B1 If you select Use fixed IP address provided by your ISP, enter a WAN IP address, WAN IP Subnet Mask
and the neighboring device’s IP address given by your ISP.
If you are given DNS server settings, enter them in the fields. Otherwise leave the default settings and click
Next.
C Select Factory Default to use the factory assigned default MAC address.
D Select the check box to have the P-334WH apply bandwidth management to traffic going out through the
WAN, LAN or WLAN port according to the traffic type.
E Click Apply to save your changes.
