Adjusting CENTER LEVEL
If desired, you can adjust the sound output level of the center
speaker even if the output level is already set in “SPEAKER
BALANCE ADJUSTMENT” on page 16–17.
Control range : +10 to –21
1
Press the CENTER/REAR/DELAY selector button once or
more so that “CENT” appears on the display.
2
By continuously pressing the LEVEL control + or – button,
the level value changes continuously.
Notes
● This adjustment can be made only when the sound field
program DOLBY PRO LOGIC or DOLBY 3 STEREO is
selected.
● Once the output level is adjusted, the level value will be
the same in the DOLBY PRO LOGIC and DOLBY 3
STEREO programs.
E-48
USING SOUND FIELD PROCESSOR
1
1
2
2
3
3
4
4
5
5
TIME
A
DISC SKIP
PROG
B
TAPE
C
EDIT
D
+ I0
E
OPEN/CLOSE INDEX MODE
6
6
7
7
8
8
9 0
CD
PRESET
TUNER
TAPE
RETURN
STOP PLAY PLAY REC/PAUSE TAPE 1/2
MUSIC
TEST FLAT CENTER/REAR
/DELAY
PROGRAM USER
POWER
INPUT SLEEP
VOLUME
REPEAT
PREV NEXT SELECT
ECHO/KEY
LEVEL
Adjusting REAR LEVEL
If desired, you can adjust the sound output level of the rear
speakers even if the output level is already set in “SPEAKER
BALANCE ADJUSTMENT” on page 16–17.
Control range : +10 to –21
1
Press the CENTER/REAR/DELAY selector button once or
more so that “REAR” appears on the display.
2
By continuously pressing the LEVEL control + or – button,
the level value changes continuously.
Notes
● This adjustment can be made when a sound field program
except DOLBY 3 STEREO is selected.
●
Adjustment can be made to DOLBY PRO LOGIC, HALL
and ARENA individually.
