The following table will translate the
zlc
output to link status.
Link Port Status Link Speed Pause Faults OK
Zre
(x) EKEY_DISA
BLED Auto Enable Internal Fault
EKEY_ENAB
LED 1000fd
UP 1000hd
DOWN 100fd
100hd
10fd
10hd
Disable External Fault
ON
Link: zre(X) – physical interface
Shelf Manager Status: EKEY_DISABLED - A slot or device that has been disabled by the Shelf
Manager.
EKEY_ENABLED - A slot or device that has been enabled by the shelf
manager and enabled by the Ethernet Switch Blade
switch.
UP – The port has been configured to be active and has established a link
with another network device.
DOWN – The port has been configured to be active but has not establish a
link with another network device.
Link Speed: Auto – Auto Negotiate with the other device. The node device
must be configured to Auto Negotiate as well or network connectivity errors
will occur.
1000fd – Full Duplex Gigabit Ethernet
1000hd – Half Duplex Gigabit Ethernet
100fd – Fast Ethernet Full Duplex
100hd – Fast Ethernet Half Duplex
10fd – Ethernet Full Duplex
Ethernet Switch Blade User's Guide release 3.2.2j page 166
