69
English
Tone Control Characteristics
Bass
Boost/Cut .............................................................................. ±10 dB (50 Hz)
Turnover frequency ........................................................................... 350 Hz
Treble
Boost/Cut ............................................................................ ±10 dB (20 kHz)
Turnover frequency ........................................................................... 3.5 kHz
BASS EXTENSION (MAIN L/R) ................................................... +6 dB (70 Hz)
Filter Characteristics (Highcut Filter)
SUBWOOFER (fc = 90 Hz) ............................................................. 24 dB/oct.
Audio muting .......................................................................................... –20 dB
Video Section
Video Signal Type
[U.S.A. and Canada Models].................................................................NTSC
[Europe, U.K. and Australia models] ...................................................... PAL
[General Model] ........................................................................... NTSC/PAL
Video Signal Level ........................................................................ 1 Vp-p/75
Ω
S-Video Signal Level
Y ............................................................................................... 1 Vp-p/75 Ω
C ........................................................................................ 0.286 Vp-p/75
Ω
Maximum Input Level ....................................................... More than 1.5 Vp-p
Signal-to-Noise Ratio ............................................................................. 50 dB
Monitor Out Frequency Response ............................... 5 Hz – 10 MHz, –3 dB
Power Supply
U.S.A. and Canada models .................................................... AC 120V/60 Hz
Europe and U.K. models ........................................................ AC 230V/50 Hz
Australia model ....................................................................... AC 240V/50 Hz
General model .............................................. AC 110/120/220/240V 60/50 Hz
Power Consumption
U.S.A. and Canada Models ........................................................450W/600 VA
Europe, U.K., Australia and General models.......................................... 400W
AC Outlets
2 SWITCHED OUTLETS
[U.S.A. model] ..................................................................... 120W max. total
[Canada and General models] ............................................ 100W max. total
1 SWITCHED OUTLET
[Europe, U.K. and Australia models] ........................................... 100W max.
1 UNSWITCHED OUTLET
[U.S.A. and Canada models] ...................................................... 180W max.
[General model] .......................................................................... 200W max.
Dimensions (W x H x D) ................................................ 435 x 170 x 476.5 mm
(17-1/8” x 6-11/16” x 18-3/4”)
Weight .............................................................................. 21.0 kg (46 lbs. 3 oz.)
* Specifications are subject to change without notice.
