22
AC–3 RF
SIGNAL
AUDIO SIGNAL AUDIO SIGNAL VIDEO SIGNAL
GND
PHONO LD
CD
1
CD
2
TUNER
3
TAPE
PB
4
REC
OUT
TAPE 1
3
TAPE
PB
4
REC
OUT
TAPE 2
COAXIAL
OPTICAL
CD
TAPE
PB
TAPE 1
REC
OUT
LD
TV/DBS
VCR 3
/DVD
DIGITAL SIGNAL
LD
VIDEO S VIDEO
TV/DBS
IN
VCR 1
OUT
IN
VCR 2
OUT
IN
VCR 3/DVD
VCR 3/DVD OUT
CAN BE USED AS A 2ND
MONITOR OUT, IF SELECTED
BY SET MENU.
OUT
MONITOR OUT
OUTPUT
GND
OUTPUT
OUTPUT
LINE OUT
LINE IN
LINE OUT
LINE IN
AUDIO OUT
AUDIO IN
VIDEO OUT
VIDEO IN
VIDEO IN
AUDIO IN
VIDEO IN
AUDIO OUT
VIDEO OUT
VIDEO IN
AUDIO IN
VIDEO OUT
AUDIO OUT
VIDEO OUT
AUDIO OUT
AC-3 RF OUTPUT
AUDIO OUT
VIDEO OUT
CONNECTING AUDIO/VIDEO SOURCE EQUIPMENT TO THIS UNIT
BASIC CONNECTIONS
*
If you have YAMAHA audio/video unit numbered as 1 , 2 , 3 , etc. on the rear panel, connections can be made easily by making sure to
connect the output (or input) terminals of each unit to the same-numbered terminals of this unit.
Monitor TV
Tuner
Tape deck 1 (DAT)
CD player
TV/Satellite tuner
Video cassette
recorder 1
LD player
Video cassette
recorder 2
Video cassette recorder 3
or another video unit
Tape deck 2
Turntable
If you wish to connect a second monitor TV (or a projector) to this
unit, you can switch the VCR 3/DVD VIDEO OUT jack (and S VIDEO
jack also) to a second monitor out jack for the connection with another
monitor TV. (See page 43.)
* For shaded parts, see pages 23 to 25.
