40
Ⅵ
Preset value of the CINEMA Equalizer
L, C, R EQ
HIGH: FRQ ............ 12.7 kHz
GAIN ........................... –3 dB
FRONT, REAR EFCT EQ
HIGH: FRQ ............ 12.7 kHz
GAIN ............................. 0 dB
Ⅵ
Frequency characteristics
The following curves show frequency characteristics when the
High-shelving equalizer (HIGH) is adjusted at the indicated values.
HIGH: FRQ ............................... 1.0 kHz
GAIN ............................. +6 dB to –9 dB
HIGH: FRQ ........... 1.0 kHz to 12.7 kHz
GAIN ................................. +6 dB/–9 dB
PEQ: FRQ ............. 12.7 kHz
GAIN ........................... –4 dB
PEQ: FRQ ............... 8.0 kHz
GAIN ........................... –3 dB
+6
+3
0
–3
–6
–9
20
50
100
200
500
1k
2k
5k
10k
20k
PEQ
HIGH
HIGH + PEQ
(OVERALL)
Frequency (Hz)
GAIN (dB)
Frequency (Hz)
GAIN (dB)
Frequency (Hz)
GAIN (dB)
Frequency (Hz)
GAIN (dB)
+6
+3
0
–3
–6
–9
20
50
100
200
500
1k
2k
5k
10k
20k
HIGH
PEQ
+6
+3
0
–3
–6
–9
20
50
100
200
500
1k
2k
5k
10k
20k
+6
+3
0
–3
–6
–9
20
50
100
200
500
1k
2k
5k
10k
20k
FREQ.
POINTS
1.0k
1.2k
1.6k
2.0k
2.5k
3.2k
4.0k
5.0k
5.7k
6.3k
7.1k
8.0k
9.0k
10.1k
11.3k
12.7kHz
