Page 34
Universal Serial
Bus (USB)
The table below provides the contact terminat-
ing assignments by number and electrical value
for the cable connectors.
Contact Number
Signal Name
Typical Wiring
Assignment
1
VBUS
Red
2
D-
White
3
D+
Green
4
GND
Black
Shell
Shield
Drain Wire
You can refer to the Universal Serial Bus Speci-
fication for details regarding this interface.
28
980348-001 Rev. A
Appendix A - Troubleshooting
