Using the

Media Cutter

Printers that have a bezel with a motorized

blade can dispense one or more forms that are

then automatically cut from the media supply.

This option cuts through continuous paper from

rolls and liner between labels. The media can

be up to 0.0055 inch (0.095mm) thick, 1.12

inch (28mm) to 4.25 inches (108mm) wide,

and at least 0.75 inch (19.1mm) long. The den-

sity of media can be up to 120 grams/meter

2

.

Blade life is 1,000,000 cuts.

Use the

OC

command to activate the cutter and

the

Q

command to set the form length and gap

distance. See the EPL2 programmer's manual.

980348-001 Rev. A

21

Using Options
