ZyXEL Communications 802.11g HomePlug AV ADSL2+ Gateway P-660HWP-D1 User Manual
P-660hwp-dx, Quick start guide
Table of contents
Document Outline
- Version 3.40
- 7/2007
- Edition 1
- Overview
- 1 Hardware Connections
- 1 DSL: Use the gray telephone wire to connect your P-660HWP-Dx’s DSL port to a telephone jack (or to the modem port on a splitter if you are using one).
- 2 ETHERNET: Use the yellow Ethernet cable to connect a computer to an ETHERNET port on the P-660HWP-Dx for initial configuration and/or Internet access.
- 3 POWER: Use only the power cable that came in the package to connect your P- 660HWP-Dx to a power outlet. Make sure the power outlet is switched on. This socket will also act as your HomePlug AV connection.
- 4 Push in the POWER button.
- 5 Look at the lights on the front panel.
- 2 Internet Connection Setup: Automatic
- 1 Open a browser such as Internet Explorer and go to your favorite website. Wait while your P-660HWP-Dx tries to detect your DSL connection to your ISP. This may take a few minutes.
- 2 After it detects the connection, the DSL light shows green on your device and the Internet light comes on when the Internet is ready for you to use. If you have a PPPoE connection, you will have to enter your user name and password.
- 3 Go to section 3 if you wish to configure your wireless settings using the wizard.
- 4 If you do not see the connection test screen, or the connection test is not successful, follow the instructions in the screen below, or check your connections and restart the P- 660HWP-Dx.
- 3 Internet and Wireless Setup Wizard
- 3.1 Log In to the Wizard
- 1 Open a browser such as Internet Explorer and enter the following URL address: http:// 192.168.1.1
- 2 Type the admin password 1234 (default). Click Login.
- 3 Type (and retype) a new password and click Apply. It is strongly recommended that you change the P-660HWP-Dx’s password and write it down.
- 4 Enter your new password to log in again.
- 5 Click Apply in the screen below to create a new certificate for your P-660HWP-Dx. This screen will continue to appear until you apply this option.
- 6 Select Go to Wizard setup in the screen below. Click Apply to access the Wizard.
- 3.2 Connect to the Internet Using the Wizard
- 1 Click INTERNET/WIRELESS SETUP. The wizard autodetects your Internet connection.
- 2 Enter your Internet connection information exactly as provided by your ISP in the screen below and click Next.
- 3 In the next screen, select either Obtain an IP Address Automatically or Static IP Address. If you select Static IP Address then fill out the required fields based on the information provided by your ISP and click Apply.
- 4 If the Internet connection test is successful, either browse to your favorite website (such as www.zyxel.com) or click Next on your screen to go to section 3.3 to configure your wireless settings.
- 3.3 Configure your Wireless Settings Using the Wizard
- 1 Select Active and click Next to continue. It is strongly recommended that Enable OTIST is NOT selected. See the Users’ Guide for more information on OTIST.
- 2 Configure your wireless settings in the screen displayed. Click Next.
- 3 If you select either WEP or WPA-PSK security (recommended), then follow the directions to enter the appropriate key. Click Next to continue and Apply to save your wireless LAN settings.
- 4 Check your configuration in the screen below and write down your wireless LAN settings for later use.
- 5 Click Finish to complete and save the wizard setup. Your Internet connection is ready for you to use. Open a browser such as Internet Explorer and navigate to a website.
- 3.1 Log In to the Wizard
- 4 Setting Up a Wireless Network
- 5 HomePlug AV Network Setup
- 1 Plug your P-660HWP-Dx and other HomePlug AV devices into power outlets and turn them on. Your P-660HWP-Dx will try to detect other HomePlug AV devices on the same electrical wiring.
- 2 Check the POWERLINE () LED for a HomePlug AV connection.
- 3 Go to Network > Powerline > Local Setting to configure the P-660HWP-Dx’s power line settings.
- 4 Go to Network > Powerline > Remote Setting to make a new network with a new Network Password and add the other HomePlug AV devices to your new network.
- 5 Go back to Network > Powerline > Local Setting to change your P-660HWP-Dx’s Network Password to the new one and connect it to your new HomePlug AV network. Type your new Network Password and click Apply.
- 6 Check the other devices you selected previously are now on the list of Remote Stations In The Same Network by going to Network > Powerline > Remote Setting. If all devices are correctly listed, your HomePlug AV network is now ready for use.
- Troubleshooting
- 1 Your computer may be set to use a static IP address in a different subnet from the ZyXEL device. See the User’s Guide for information on setting up your IP address.
- 2 If you are using Internet Explorer in Windows XP or Windows Server 2003, make sure you allow pop-up windows, JavaScript and Ja...
- 1 Check your connections and restart the device.
- 2 Contact your ISP to check the status of your account.
- 1 Log in to the P-660HWP-Dx’s web configurator. (See section 3.1.)
- 2 Select Go to Advanced setup and click Apply.
- 3 The Status screen appears. Click Network > WAN in the navigation panel on the left of the screen.
- 4 Ensure that the settings in this screen are the same as those your ISP gave you. If your ISP gave you a static IP address to u...
- 1 Check you have correctly entered the information your ISP gave you.
- 2 If you are using Bridge mode (check Mode in the Network > WAN > Internet Connection screen) click NAT > General and ensure Act...
- 3 Click the wizard icon ( ). Run the Internet/Wireless Setup wizard again.
- 4 Contact your Internet Service Provider to check the status of your account.
- 5 If you still have problems, see Troubleshooting in the User’s Guide.
- 1 Make sure that the network password is the same on all of your HomePlug AV adapters and that the DAKs for your HomePlug AV devices are typed correctly.
- 2 Make sure that all the power line adapters you are using are HomePlug AV compliant. The P-660HWP-Dx does NOT recognize earlier versions of HomePlug adapters such as HomePlug 1.0 or 1.0.1.
- 3 Plug a second HomePlug AV adapter into an adjacent outlet (to your P-660HWP-Dx) and see if the POWERLINE LED lights up. This checks whether the P-660HWP-Dx can detect the power line adapters on your electrical circuit.
- Viewing Your Product’s Certifications
