3. Close the door.
4. Set the maximum oven temperature and let the oven
operate for 1 hour.
5. Clean the oven cavity with a soft and damp sponge.
Caution! Do not attempt to clean catalytic surfaces
with oven sprays, abrasive cleaners, soap or other
cleaning agents. This may damage the catalytic surface.
Discolouration of the catalytic surface has no effect
on catalytic properties.
Shelf Support Rails
Removing the shelf support rails
1 Pull the front of the
shelf support rail away
from the side wall.
2 Pull the rear shelf sup-
port rail away from the
side wall and remove it.
Installing the shelf support rails
Install the shelf support rails in opposite sequence.
The rounded ends of the shelf support rails must
point to the front!
Oven door and glass panels
To clean the oven door remove it.
Caution! Be careful when you remove the door from
the appliance. The door is heavy!
Removing the oven door
1. Open the oven door as far as it goes.
2. Lift up clamping levers (A) on the two door hinges
fully.
A
A
3. Close the oven door until the first position (angle
approx. 45°).
45°
4. Hold of the oven door with one hand on each side
and pull it away from the oven at an upwards angle.
Put the oven door with the outer side down on a soft
and level surface to prevent scratches.
5. Now you can remove the inner glass panels and
clean them.
To install the door follow the procedure in reverse.
The oven door has 2, 3 or 4 panels of glass (de-
pends on the model)
Removing and cleaning the door glasses
1. Hold the door trim (B) on the top edge of the door at
the two sides and push inwards to release the clip
seal.
B
2. Pull the door trim to the front to remove it.
17
