CONTROL I/O CHARACTERISTICS
[NETWORK] Connector (100Base-TX Ethernet, RJ-45)
Terminal Format Level Connector
GPI
IN – 0–5V
EUROBLOCK *1
(3.5mm pitch)
OUT – TTL
+V – 5V
Ethernet IEEE802.3 10Base-T/100Base-TX RJ-45
USB USB 1.1 Function – Type B
REMOTE RS-232C/RS-422 RS-232C/RS-422 D-SUB 9P (Male)
*1 Inputs: 8 channels, Outputs: 4 channels
Inputs: Not apply 2 wire Fader mode
Outputs: Imax/pin = 16mA
Outputs: VH = 2.5V(min.), VL = 0.6V(max.)
Pin Connection
1 TxD+
2 TxD–
3 RxD+
4 Unused
5 Unused
6 RxD–
7 Unused
8 Unused
