Chapter 3 VLC Troubleshooting
VLC1324G User’s Guide
33
3.6 The Line Card is Not Manageable
The line card always uses the default configuration. Any changes you did to the line card are
stored on the MSC. By default, the MSC is allowed to manage every line card. Use the
lcman
show command on the MSC to see a line card’s connection status. If you still cannot manage
the line card from the MSC, the line card’s configuration file may be damaged or the firmware
may be old, you may need to restore the default configuration file or upload new firmware
using the line card’s console port.
1
The MSC resets the line card after a period of inactivity on the line card. This
may damage the line card if you are uploading the default configuration file or
new firmware to the line card. Use the
lcman disable
command on
the MSC to prevent the MSC from managing the line card.
1
After you upload the file successfully, use the
lcman enable
command
on the MSC to allow the MSC to manage the line card again.
3.6.1 Uploading the Default Configuration File via Boot Commands
Obtain the default configuration file, unzip it and save it in a folder. Use a console cable to
connect a computer with terminal emulation software to the line card’s console port. Pull out
the line card and push it back in, you will see the initial screen. When you see the message
Press any key to enter Debug Mode within 3 seconds press any key to enter
debug mode.
To upload the configuration file, do the following:
1 Type atlc after the Enter Debug Mode message.
2 Wait for the Starting XMODEM upload message before activating XMODEM
upload on your terminal.
3 This is an example Xmodem configuration upload using HyperTerminal. Click
Transfer, then Send File to display the following screen.
Figure 9 Example Xmodem Upload
Type the configuration file's
location, or click Browse to
search for it.
Choose the 1K Xmodem
protocol.
Then click Send.
