Chapter 2 VLC Specifications
VLC1324G User’s Guide
29
Figure 8 Console Cable Mini RJ-11 Male Connector
2.6 VSC1224-41
The following table lists the splitter card specifications.
2.7 VSC1224-43U
The VSC1224-43U provides an impedance of 135 ohms and 150 ohms for ISDN.
Table 7 Console Cable Connector Pin Assignments
MINI RJ-11 MALE
Pin 2: TXD
Pin 3: RXD
Pin 4: GND
Table 8 VSC1224-41 CO Impedance Splitter Card Specifications
COUNTRY
POTS
Taiwan 900
Ω
Others
600
Ω
