Zenoah BC3410FW User Manual
Page 7
Fig.7 GEARCASE
Fig.8 ACCESSORIES
BC3410FW/BC4310FW
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
4000-13000 GEARCASE ASSY
1
1
3541-13194 • GEARCASE
1
2
06000-06000 • BEARING
1
3
06000-06201 • BEARING
1
4
3180-13141 • SEAL
1
5
04065-03212 • RING
1
6
4050-13210 • SHAFT
1
7
3180-13220 • GEAR
1
8
3541-13241 • HOLDER A
1
9
3541-13251 • HOLDER B
1
10
3310-43210 • WASHER
1
11
01643-30823 • WASHER
1
12
3579-33260 • BOLT
1
M8, Left
13
01252-30510 • BOLT
1
M5xL10
14
0224-40610 • BOLT
1
M6xL10
15
3540-13260 • BOLT
1
M6xL35
16
3541-13311 • PINION
1
17
06000-06000 • BEARING
1
18
06001-06000 • BEARING
1
19
3180-13330 • RING
1
20
04065-02612 • RING
1
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
6041-99220 SHAFT
1
2
6041-99240 SHAFT
1
3
T3219-15101 TAP HEAD ASSY
1
4
T3219-15111 • CASE
1
5
T3189-15191 • EYELET
2
6
T3189-15132 • COVER
1
7
T3189-15142 • COAD HOLDER
1
8
T3189-15160 • SPRING
1
9
848BU369S0 • CORD
1
10
3520-91110 BAG
1
11
3532-91000 TOOL SET
1
12
1030-91340 • DRIVER
1
13
3239-91310 • SOCKET
1
14
09007-00425 • WRENCH
1
for M5
15
09007-00528 • WRENCH
1
for M6
16
3540-91110 • BAR
1
17
3540-91120 • SPANNER
1
