Component Identification
8
NOTE: Control Identification
shown in Operating
Instructions section.
Grass Handling System
9.5 Bushel Catcher Standard
7.0 Bushel Catcher (Optional)
(Not Shown)
Anti-Scuff
Roller
Deck
Caster Wheels
Catcher Door
Safety Latch
Counterweight Spring
and Protective Cover
Tilt-Up
Latch
Transmission Control Rod
Adjustment Nut (RH)
Transmission Control Rod
Adjustment Nut (LH)
Deck Lift Handle
(Cutting Height Adjustment)
Tilt-Up
Deck Handle
Catcher Lift /
Dump Handle
Turbine
Precleaner
Fuel Tank
and Cap
Deck Support Pins
and Height Adjustment
Hitch Pins
Footrests
Tilt-Up
Hook
Deck Support
Arm (RH)
Spring Clip
Front View and Right Side View
