Page 11

Specifications

MODEL

AIR COOLED
MT (23.0 HP)
MTEFI (26.0 HP)

LIQUID COOLED
MTL (25.0 HP
MTLEFI (31.0 HP)

GHS SYSTEM (Optional) (continued)

Optional Grass Catcher
Capacity

65 Gallons (246 liters)/
7.0 Bushels

Full Signal (Grass-Pak

Switch)

Oscillating Vane Switch
Mounted on Grass Delivery
Spout Triggers Horn Signal

Powerfil

Oscillating Delivery Spout
Driven by 12 Volt Electric
Gearmotor Spreads Material
throughout Interior of Catcher
@ 25 Cycles/Minute

SEAT

Contour-Molded, with Nylon
Backed Vinyl Cover and
Integral Foam Cushion

FRAME/BODY CONSTRUCTION

Frame

All Welded Unitized Steel
Chassis

Body

14 Gauge Steel

Deck

11 Gauge Steel

GHS Catcher and Chutes

Molded Cross-Linked
Polyethylene (UV Stabilized)

**Dimensions and weight shown are for 48 in. (122 cm) GHS Model (typical).

Dimensions for Tractor and Mower with 42 in. (107 cm) deck are:

Length = 88 in. (224 cm)
Width = 43 in. (110 cm)

For SD Models, subtract 7 in. (18 cm) from the height.
Deck weight for 48 in. (122 cm) Tilt-Up deck = 205 lb (93 kg). Deck sizes range from 42 to 74 in.
(107 to 188 cm), with corresponding deck weights ranging from 170 to 400 lb (77 to 181 kg).
Optional (7.0 Bushel) Grass Catcher subtracts approx. 5 lb (2 kg) and 5 in. (13 cm) in Height

NOTE: The manufacturer reserves the right to make changes in specifications shown herein at any time
without notice or obligation.
