Service Name
The NAT service for which you are configuring Port Forwarding.
Type
The type of NAT service configuration you selected.
Protocol
The type of Protocol that is used to run this NAT service.
TCP- Transmission Control Protocol.
UDP-User Datagram Protocol (UDP).
Local IP Address
If a static IP address has been assigned, it will be displayed here.
Base Host Port
The port on the WAN that will host the NAT service selected.
13.3 Port Forwarding Trigger Ports
To select Port Forwarding Trigger Ports, click on define custom service from the Service Configuration screen,
and then select Trigger Ports from the Custom Service screen. Click on next. The follow settings will be displayed
in the Trigger Ports screen. Enter your values in the Local ‘Trigger’ Port Range fields and click on next to
continue.
Service Name
The NAT service you selected.
Local Trigger Port Range
The local LAN side TCP/UDP port.
Global Port Range
The WAN side TCP/UDP port range.
