Page 11
FM / AIR
ANTENNA 2
ANTENNA 1
EXT DC
INPUT
MASTER
POWER
SHORTWAVE
ANTENNA
SELECT
FM / AIR
ANTENNA
SELECT
LINE
AUDIO
OUT
EXTERNAL
SPEAKER
AIR
SQUELCH
9VDC/
1Amp
+
50
300
GND
500
50
4
EXT WHIP
1 2 WHIP
MADE IN U.S.A.
/ 8
ON OFF
CAUTION:
BALANCED OUTPUT.
DO NOT GROUND.
BATTERY COMPARTMENT
Installation, continued 5
LOW IMPEDANCE
ANTENNA
HIGH IMPEDANCE
ANTENNA
OR
BUILT-IN
TELESCOPING
WHIP ANTENNA
50 OHM COAXIAL CABLE
PL-259
CONNECTOR
PLUG INTO 120VAC,
60Hz AC POWER
TO
TAPE RECORDER
INPUT
FIGURE 3 - INSTALLATION DIAGRAM
- NOTE -
CHECK INTERNAL
BATTERIES PERIODICALLY
IF INSTALLED
EXTERNAL SPEAKER
DO NOT GROUND
NOTE:
Grounding of either speaker
output wire will limit maximum
available audio output and
damage the SW8.
TV/FM
SPLITTER
OR
AC
ADAPTOR
75
0
MS8 Speaker
