Specifications
5
MODEL MS
DIMENSIONS (continued)
Height
SD Model 37-1/2 in. (95 cm)
GHS Model 44-1/2 in. (112 cm)
Wheel Base (Tractor) 42-1/4 in. (107 cm)
Tread Width (Tractor)
Standard Tires
28-1/4 in. (72 cm)
Optional Tires 29-3/4 in. (76 cm)
MOWER DECK
Width of Cut SD/GHS 36 or 42 in. (91 or 107 cm)
Cutting Height 1 to 4 in. (3 to 10 cm)
Height Adjustment 7 Positions - 1/2 in. (1 cm) Increment Hitch Pins Installed in
Multi-Position Deck Support
Blade Size
36 in. (91 cm) SD Model 20 in. (51 cm) Two (2) Clockwise-Rotating Blades with a 4 in.
(10 cm) Center Overlap
36 in. (91 cm) GHS Model 20 in. (51 cm) Two (2) Counter-Rotating Blades with a 4 in.
(10 cm) Center Overlap
42 in. (107 cm) SD Model 22 in. (56 cm) Two (2) Clockwise-Rotating Blades with a 2 in.
(5 cm) Center Overlap
42 in. (107 cm) GHS Model 22 in. (56 cm) Two (2) Counter-Rotating Blades with a 2 in.
(5 cm) Center Overlap
Deck Suspension Torsion-Flex Frame with Caster Wheels and
Counterweight Springs
CURB WEIGHT (Approximate)
SD Tractor Only 490 lb (224 kg)
GHS Tractor Only 565 lb (256 kg)
SD Tractor and 36 in. SD Deck 635 lb (288 kg)
SD Tractor and 42 in. SD Deck 670 lb (304 kg)
GHS Tractor and 36 in. GHS Deck 715 lb (324 kg)
GHS Tractor and 42 in. GHS Deck 735 lb (340 kg)
DRIVE BELTS
Engine PTO Walker P/N 5230-2
Gates BX30
Ground Drive Walker P/N 5232
Gates 6847
PTO Drive
SD Model Walker P/N 5234-1
Gates 6935
PTO Drive
GHS Drive
Walker P/N 5234-2
Gates 6944
