Specifications
4
MODEL MS
TRANSMISSION (continued)
Transmission Fluid
Factory Service Mobil 1 Synthetic Motor Oil (15W-50)
Transmission Fluid Capacity 1 qt (1 liter)
Transmission Cooling Cooling Fan Mounted on Drive Pulley
Ground Travel Speed
Forward m.p.h. (km/h)
Reverse m.p.h. (km/h) 0-5 (0-8) Infinitely Variable
0-5 (0-8) Infinitely Variable
BLADE DRIVE
PTO Shaft Sliding Spline Shaft with Two (2) High-Speed U-Joints
Blade Spindle Each Blade (2) Mounts Direct on Peerless Right Angle
Gearbox with Tee Gearbox in Center Connected to PTO Shaft
(Complete Geared Drive, Peerless Model 1000 Gearboxes)
Blade Drive Clutch and Brake Manual Belt Tightener Clutch and Scrubber Brake
(Stops Blades within Five (5) Seconds of Disengagement)
Max. Blade Speed
[22 in. (56 cm) Blade] @ 3600
RPM Engine 2900 RPM
[16700 FPM (5090 m/min)]
TIRE SIZE
Deck Caster Wheel 2.80/2.50-4 Pneumatic (4-Ply)
Deck Caster Wheel (Optional) 8.25 x 2.75 (Semi-Pneumatic)
Drive 18 x 6.50-8 (4-Ply)
Drive (Optional Wide Tire) 18 x 8.50-8 (4-Ply)
Rear 13 x 6.50-6 (4-Ply)
TIRE PRESSURE
Deck Caster Wheel 20 PSI (137 kPa)
Drive 15 PSI (103 kPa)
Rear
20 PSI (137 kPa)
DIMENSIONS (Tractor and Mower)
Length
36 in. (91 cm) GHS Model 87 in. (221 cm)
42 in. (107 cm) GHS Model 89 in. (226 cm)
Width
36 in. (91 cm) SD Model
(with Deflector) 41-3/4 in. (106 cm)
42 in. (107 cm) SD Model
(with Deflector) 47-3/4 in. (121 cm)
36 in. (91 cm) GHS Model 37 in. (94 cm)
42 in. (107 cm) GHS Model 43 in. (109 cm)
