Specifications
3
MODEL MS
ENGINE
Manufacturer/Model Kawasaki, FE 400D, 1 Cyl. OHV (Air-Cooled)
Displacement 24.5 cu. in. (401 cc)
HP (@ 3600 RPM) 13.0
Max. RPM (No Load) 4000
Governed RPM 3600
Max. Torque [ft-lb (N
⋅
m) @ RPM] 19.5 (26.4) @ 2500
Idle RPM 1300
Spark Plug Type NGK BPR5ES
Spark Plug Gap .030 in. (.75 mm)
Crankcase Capacity 1.35 qts (1.3 liters)
Crankcase Lubricant API SC/SD/SE/SF/SG/SH Grade Oil Only with 10W-30/10W-40
Viscosity or 40W Above 68° F (20° C) Only
Fuel Tank Capacity 1.7 Gallons (6.4 liters)
Fuel Automotive Grade Unleaded Gasoline (87 Octane)
Cooling System Air Cooled
ELECTRICAL SYSTEM
Battery 12 Volt, 230 CCA (Interstate SP-30)
Charging System Flywheel Alternator
Charging Output 13 Amp DC (Regulated)
System Polarity Negative Ground
Ignition Transistorized Electronic Magneto
Starter 12 Volt Electric Key and Solenoid Operated
Interlock Switch Ignition Lockout by Seat Switch, Transmission Neutral and Blade Clutch
TRANSMISSION
Manufacturer/Model Dual Hydrostatic, Eaton Model 7, Each Wheel Independently Driven
Steering Hand Lever Control / Individual Wheel
Forward Speed Control Precision Friction Lock Lever, Cruise Control, with Neutral-Park
Position
Service Brake Dynamic Braking through Hydrostatic Transmission
Parking Brake Mechanical Pin Lock in Transmission Gear
Neutral Transmission Release by Manual Dump Valve
Final Drive Gear Drive Axle
