57
Maintenance Instructions
REPLACING/REPAIRING
REPLACING/REPAIRING
IMPORTANT: ALWAYS use genuine factory re-
placement parts. Substitute parts CAN result in
product malfunction and possible injury to the oper-
ator and/or others.
Drive Belts
There are three (3) individual belts on the machine:
•
Engine Belt
•
PTO Drive Belt
•
Ground Drive Belt
The belts may be removed and replaced using the
procedures described on the following pages.
DANGER
To prevent accidental starting of the en-
gine when replacing parts or repairing the
machine, remove the key from the ignition
switch and disconnect the spark plug wire.
PTO Drive Belt
Ground Drive Belt
Engine Belt
Belt Locations
