Please Do Not Return This Product To The store. Call us Directly! Our trained technicians Will answer your questions and/or Ship any Parts
you May Need. you can reach us toll free at
1-888-827-3667 for Consumer assistance or online at www.wayne-dalton.com
17
tools Needed:
IN
sT
All
ATION
If u-baR IS INStallED
8
Power Drill
7/16” Socket
Driver
(2) Saw horses
Operator bracket
NOTE: If installing a trolley type operator,
complete this step. If not, skip this step
and continue with Step 9.
IMPORTANT: WhEN CONNECtING a
tROllEy tyPE GaRaGE DOOR OPENER
tO thIS DOOR, a WayNE-DaltON
OPENER/tROllEy bRaCkEt MuSt
bE SECuREly attaChED tO thE tOP
SECtION Of thE DOOR, alONG WIth
aNy u-baRS PROVIDED WIth thE
DOOR. thE INStallatION Of thE
OPENER MuSt bE aCCORDING tO
MaNufaCtuRER’S INStRuCtIONS aND
fORCE SEttINGS MuSt bE aDjuStED
PROPERly.
NOTE: for retro fit applications, the
operator bracket must be aligned with
an existing operator
If no u-bar is installed:
locate the center of the top section and
attach the operator bracket as shown in
the illustration using (6) 1/4” - 20 x 5/8”
self drilling screws.
If u-bar is installed:
Remove, but retain (4 to 6)
1/4”- 20 x 7/8” self drilling screws
from the center of the u-bar. locate
the center of the top section and slide
operator bracket under u-bar till the
operator bracket is seated against the
u-bar flange. attach the operator bracket
using (6) 1/4” - 20 x 5/8” self drilling
screws (as shown). Reattach the u-bar
using the self tapping screws removed
previously.
OPERatOR
bRaCkEt
OPERatOR
bRaCkEt
u-baR
u-baR
1/4”- 20 x 7/8” SElf
DRIllING SCREWS
SIDE VIEW Of u-baR
u-baR
OPERatOR bRaCkEt
IN PlaCE uNDER
u-baR
(6) 1/4”- 20 x 7/8”
SElf DRIllING
SCREWS
If NO u-baR IS INStallED
( 6) 1/4”-20 x 5/8”
SElf DRIllING
SCREWS
OPERatOR bRaCkEt
CENtERED IN thE
MIDDlE Of tOP SECtION
SIDE VIEW
OPERatOR
bRaCkEt
alIGNED WIth
tOP Of SECtION
