630-960-0 - pg5-10, Motor – Windsor High Speed Burnisher LB2000IA User Manual
Page 25
MOTOR
86309600 (2000) BURNISHER 10/08/08
5-10
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1A 86312260
-
1
MOTOR, 115V 1.5HP
20000RPM
LB2000, UB20000F
1B 86312250
-
1
MOTOR, 230V 1.5HP
20000RPM
LB2000I, LB2000IA
2
86217490
27884
1
COVER, MOTOR 1.25HP
3
86223690
70702
3
SCR, M5 X .8 X15MM BLK
4 86010790 87163 4
WASHER, 3/8 SPLIT LOCK
PLTD
5 86006920 70507 4
SCR, 3/8-16 X 3/4 HHCS GR5
PLT
6
86219610
48082
1
KEY, 3/16 SQ X .85 LG CRS
MOTOR COMPONENTS (NOT SHOWN)
PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
86223460
67499
1
RECTIFIER, 50A 1000V BRIDGE
86001720
140785
1
BRUSH SET (PKG OF 4)
86003660 34378 1 FUSE
86003670 34379 1 FUSE
HOLDER
86223980 09134 1
SEALED BALL BRNG, 25 MM X
52MM
BOTTOM
MOTOR
BEARING
86001020
09135
1
SEALED BALL BRNG, MOTOR
TOP
MOTOR
BEARING
