Windsor High Speed Burnisher LB2000IA - Manual (Page 21)

HANDLE-LOWER
86309600 (2000) BURNISHER 10/08/08 5-6
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 86276810 70738 1 SCR, M5 X .8MM X 10 MM PPHMS BLK
2 86198450 20005 1 CLAMP, 5/16 NYLON
3 86223490 67468 2 RING, 10MM EXT SNAP, DIN 471
4 86222570 66340 1 PIN, DOWEL 10MM DIA X 124 MM LG
5 86215480 140421 1 BRACKET, HANDLE LINK
6 86223500 67469 2 RING, 13MM EXTERNAL SNAP
7 86288760 87234 2 WASHER, 14MM ID X 36MM OD X 2MM
8 86225720 87203 6 WASHER, 14MM ID X 36 MM OD
9 86224310 730052 1 SPACER, LINKAGE
10 86288770 500542 1 LABEL, HANDLE RELEASE
11 86221720 51358 1 LATCH, HANDLE
12 86226020 89206 2 WHEEL, 5D X 1.25 X 13MM ID GRY
13 86224590 730055 1 SPRING, 180 DEGREE TORSION
14 86215390 140420 1 BLOCK, SPRING COMPRESSION
15 86224580 730054 1
SPRING, COMP 1.140 OD X 8.40 L X
.150 W
16 86005770 57119 1 NUT, 3/8-16 HEX NYLOCK
17 86279510 87171 2 WASHER, 3/8 FLAT
18 86274000 70069 1 SCR, 3/8-16 X 3 HHCS GR5
19 86215470 140419 2 BRACKET, HANDLE MOUNT
20 86136640 70262 2 SCR, M8-1.25 X 20 HHMS PLTD
21 86137280 87054 2 WASHER, M8 FLAT DIN125A PLT
22 86215030 05157 1 AXLE, REAR
23 86223710 70733 4 SCR, M6 X 25 SHCS PLTD
24 86225010 730053 1 STRIKER, LATCH
25 86288740 70709 2 SET SCR, 8MMX1.25MM CUP PT
NOTE: Grease contact surfaces of Items 14 and 15 as necessary when servicing.
