LID/DECAL GROUP PARTS LIST
WAV 86038510 05/15/07 5-10
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86003780 35171 1 GASKET, ACCESSORY PORT
2 86234760 27674 1 COVER, ACCESSORY PORT
3 86006500 70024 2 SCR, #8 X 1/2 SHT METAL SS
4 86031930 51335 1 LID, WAV
5 86237590 35207 2 GASKET, FOAM 1/2 X 10
6 86255240 73838 1 SPRING, .24OD X 2.0 COMP
7 86006290 66285 2 PIN, .250 X .75 CRS
8 86245590 50758 1 LABEL, WAVE LOGO RIGHT
9 86245580 50757 1 LABEL, WAVE LOGO LEFT
10 86246560 50776 1 LABEL, WARNING
11 86245620 50762 1 LABEL, BRUSH HEIGHT ADJ.
12 86245600 50759 1 LABEL, WINDSOR LOGO
13 86000070 02083 1 BRUSH, 3" DUST
14 86274520 70233 6 SCR, #10 X 3/8 PH HI-LO PLTD
15 86002990 27744 3 CLIP, C 1-1/2 PLASTIC
16 86283600 02085 2 BRUSH, UPHOLSTERY
17 86000080 02084 1 TOOL, 5" UPHOLSTERY
18 86000160 02292 1 TOOL, 11" PLASTIC CREVICE
