BRUSH HEIGHT AND WHEEL GROUP PARTS LIST
WAV 86038510 07/24/07
5-4
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86005860
57273
1
NUT, 1/4-20 X 12MM HEX BARREL
2 86008200 73996 1 SPACER,
.50OD X .37ID X .44L SS
3
86006660
70190
1
SCR, 1/4-20 X 1/2 BHCS DL
4
86008750
80673
1
KNOB, WITH 1/2-13 F-INSERT
5
86001170
140054
1
BUSHING, BRZ 3/8-16 X .74 X .50
6 86279290 89131 1 WELDMENT,
FRAME
7
86001220
140177
1
BRACKET, AXLE HANGER
8
86091480
14351
1
BAR, HEIGHT ADJUSTMENT
9
86092030
14353
1
BRKT, HEIGHT ADJ RIGHT
10
86010910
89094
2
WHEEL, 1-5/8D CUSHION
11
86259960
89506
2
WHEEL, 1 15/16” x 10” HOOSIER
1012505000207
WAS 89279
12
86010790
87163
1
WASHER, 3/8 SPLIT LOCK PLTD.
13
86001660
41236
2
HUBCAP, 5/8" SHAFT
14
86270880
57032
2
NUT, 3/8-16 SERRATED FLG.
15
86005680
57047
4
NUT, 1/4-20 NYLOCK PLTD.
16
86080800
62623
1
PLATE, AXLE MOUNTING
17
86279420
87156
2
WASHER, .75ID X 1.25OD X .125
18
86000390
67376
1
ROD, .625 X 25.30 CRS
19
86010740
87090
8
WASHER, 1/4ID X 3/4OD
20
86010730
87088
3
WASHER, 3/4ID X 1.00 PLTD.
21
86010660
87025
4
WASHER, 1/4 LOCK EXT. STAR SS
22
86007740
73362
1
SPRING, EXT .5OD X 1.75L X .06W
23
86006920
70507
1
SCR, 3/8-16 X 3/4 HHCS GR5 PLTD.
24
86275570
70505
8
SCR, 1/4-20 X 1.0 HHCS PLTD.
