UNASSEMBLED PARTS
Steering Wheel
(1) Shoulder
Bolt 5/16-18
(1) Washer
17/32 x 1-3/16 x 12 Gauge
Steering
Wheel Insert
Seat
(1) Large Flat Washer
(1) Locknut 5/16-18
(1) Hex Bolt 5/16-18 x 1-1/4
(1) Hex Bolt
3/8-16 x 1
(1) Lockwasher 3/8
Steering
Boot
Steering
Extension
Shaft
Steering Wheel
Adapter
(2) Keys
Slope Sheet
Keys
(1) Lock Washer 1/2
(1) Hex Bolt 1/2-13 x 1
43
TRACTOR -- MODEL NUMBER 259723
LIFT ASSEMBLY
1
159460
Wire Asm Inner/Sprg W/plunger LT
2
159471
Shaft Asm Lift
3
105767X
Pin Groove 1 500 Zinc
4
12000002
E Ring #5133-62
5
19211621
Washer Pltd 21/32 X 1 X 21ga
6
120183X
Bearing Nylon Blk 629 Id
7
109413X
Grip Handle bicycle Matte
8
124526X
Button Plunger Red
11
139865
Link Lift LH
12
139866
Link Lift RH
13
4939M
Retainer Spring
15
167253
Link Front
16
73350800
Nut Jam Hex 1/2-13 Unc
17
130171
Trunnion Blk Zinc
18
73800800
Nut Lock W/Wsh 1/2-13unc
19
139868
Arm Suspension Rear
20
163552
Retainer Spring Zinc
31
140302
Bearing Pvt Lift Spherical
32
73540600
Nut Crownlock 3/8-24
KEY
PART
NO.
NO.
DESCRIPTION
NOTE: All component dimensions given in U. S.
inches 1 inch = 25/4 mm
