OPERATION
These symbols may appear on your tractor or in literature supplied with the product.
Learn and understand their meaning.
BATTERY
CAUTION OR
WARNING
REVERSE
FORWARD
FAST
SLOW
ENGINE ON
ENGINE OFF
OIL PRESSURE
LIGHTS ON
FUEL
CHOKE
MOWER HEIGHT
PARKING BRAKE
LOCKED
UNLOCKED
REVERSE
NEUTRAL
HIGH
LOW
ATTACHMENT
CLUTCH ENGAGED
MOWER LIFT
DANGER, KEEP HANDS AND FEET AWAY
FREE WHEEL
(Automatic Models only)
OVER TEMP
LIGHT
PARKING BRAKE
IGNITION
ATTACHMENT
CLUTCH DISENGAGED
P
KEEP AREA CLEAR
SLOPE HAZARDS
15
°
15
°
15
°
(SEE SAFETY RULES SECTION)
39
TRACTOR -- MODEL NUMBER 259723
ENGINE
1
157626
Control Th/ch LH Flag
2
17720410
Screw Hex Thd Cut 1/4-20x5/8 T
3
- - - - - - -
Engine Tecumseh, Model No. OHV 130
(Order parts from engine manufacturer)
4
156700
Muffler
13
165291
Gasket Eng 1 313 Id Tin Plated
14
13280336
Nipple Pipe 4-1/2
15
13200300
Elbow Std 90 Degree 3/8-18 Npt
16
11050600
Washer Lock Ext Tooth 3/8
23
169837
Shield Browning/Debris Guard
29
137180
Kit Spark Arrestor (Flat Scrn)
31
109202X
Tank Fuel Front 1 25
32
140527X
Cap Asm Fuel Top Vented
33
123487X
Clamp Hose Blk
37
137040
Line Fuel 20"
38
- - - - - - -
Plug Oil Drain
(Order parts from engine manufacturer)
40
124028X
Bushing Snap Nyl Blk Fuel Line
44
17490412
Screw Hexwsh Thdrol 1/4-20 x 3/4
45
17000612
Screw 3/8-16 x 3/4
46
19091416
Washer 9/32 x 7/8 x 16 ga
62
10040500
Washer Lock Hvy Hlcl Spr 5/16
72
71070512
Screw Hex Hd Cap 5/16-18 X 3/4
78
17060620
Screw 3/8-16 x 1-1/4
81
73510400
Nut Keps Hex 1/4-20 UNC
KEY
PART
NO.
NO.
DESCRIPTION
NOTE: All component dimensions given in U. S.
inches 1 inch = 25/4 mm
