Weil-McLain 800058000-Brn-PO Rie F5 - Manual (Page 9)

3223
6
GB
INTERNAL FACTORY WIRING
CAPACITOR
PUMP VALVE
MOTOR
(COIL)
EL
EC
TR
ON
IC
AI
R
S
H
UTT
E
R A
S
S
Y
.
D7328
Key to lay-out:
A - Brown
B - White
C - Blue
D - Black
6 - 120V source activates shutter open
11 - motor lead 120V source
- 120V control lock out alarm terminal
AUX - costant 120V auxiliary terminal - electronic air shutter
RIELLO 40 F3 - F5 SERIES OIL BURNERS EQUIPPED
WITH AN ELECTRONIC AIR SHUTTER
INTERNAL FACTORY WIRING
ATTENTION !!
³ Do not swap neutral and phase over, follow the diagram shown carefully and carry out a good earth
connection.
³ Minimum wire size AWG 18.
³ All wiring must be done in accordance with existing codes, both national and local.
