PACKAGE CONTENTS LIST
Your Riello 40 burner should include the following parts. Please check to make sure all parts are present before begin-
ning the installation.
SERIAL NUMBER IDENTIFICATION
Your Riello burner may have been manufactured in more than one location and therefore there are two possible serial
number identification.
The Riello 9 character serial number, example,
06 01 12345, is identified as follows:
06
= Last two digits of the year of manufacture;
01 = Week of manufacture;
12345 = Increment of 1 for each burner produced – specific
to product code – reset to zero each January 1
st
.
The Riello 15 character serial number, example,
06 A 8511111 00025, is identified as follows:
06
= Last two digits of the year of manu-
facture;
A = BI-week of manufacture;
8511111 = Burner product code;
00025
= Increment of 1 for each burner pro-
duced – specific to product code –
reset to zero each January 1
st
.
Quantity Description Code
1 Burner with
combustion head mounted C8512519 - C8512520 - C8512521
1
Mounting gasket C6880016
1 Parts bag 2569525
1 Parts bag 2569526
1 Installation manual
C6501071
Separate carton - OEM burners shipped with combustion head mounte
d
Parts bag 2569525 Parts bag 2569526
Quantity Description Quantity Description
1
1
1
1
1
1 By-pass plug
Female ¼” NPT adapter
Male 3/8” NPT adapter
2.5 mm Allen key
Oil pump connector (supply)
Oil pump connector (return)
2
2
2
4
2 Semi-flange bolts (long)
Semi-flanges
Mounting flange bolts (short)
Nuts
Chrome nuts
(06) (01) (12345)
Year of
manufacture
BI-week of
manufacture
Increment
(06) (A) (8511111) (00025)
Year of
manufacture
BI-week of
manufacture
Increment
BI-week of
manufacture
