14
SPARE PARTS LIST
No. CODE F5 DESCRIPTION No. CODE F5 DESCRIPTION
1 C8111227
•
BURNER BACK COVER
2 3006992
•
PIPE CONNECTOR - SUPPLY
3 3006571
•
3/8” NPT/METRIC ADAPTER - MALE
4 3006993
•
PIPE CONNECTOR - RETURN
5 3005847
•
1/4” NPT/ METRIC ADAPTER - FEMALE
6 3007077
•
CRUSHABLE METAL WASHER
7 3007568
•
BLEEDER
8 3007028
•
O-RING - PUMP PRESSURE REGULATOR
9 3007202
•
REGULATOR SCREW
10 3007162 C7010002
•
O-RING - PUMP COVER
11 3005719
•
PUMP SCREEN
12 3006925
•
VALVE STEM
13 3007203
•
VALVE STEM PLATE
14 3007029
•
O-RING - VALVE STEM UPPER
15 3007156
•
O-RING - VALVE STEM LOWER
16 3007268
•
NOZZLE OUTLET FITTING
17 3007087
•
CRUSHABLE METAL WASHER 5/8” ID
18 3001157 C7001029
•
PRIMARY CONTROL 530SE/C
19 3002278
•
PRIMARY CONTROL SUB BASE
20 3006553
•
COIL U-BRACKET AND KNURLED NUT
21 3002279
•
COIL
22 3007802
•
PUMP
23 3000443
•
PUMP DRIVE KEY
24 3005843
•
MOTOR
25 3007316
•
AIR TUBE COVER
26 3002280
•
PHOTOCELL
27 3005854
•
SEMI FLANGE (2 REQUIRED)
29 3020248
•
MOUNTING GASKET
30 3005708
•
FAN
31 3005844
•
CAPACITOR 12.5 µF
32 3007320
•
ACOUSTIC LINER
33 3007204
•
MANUAL AIR SHUTTER
34 3020249
•
ELECTRONIC AIR SHUTTER
35 C7001082
•
F5 REPLACEMENT AIR DAMPER KIT
OPTIONAL
60 C7001085
•
TYPE L 24V SWITCHING RELAY
61 C7001033
•
AMULET - CERAFELT SLEEVE KIT
3007943
•
CAPILLARY PORT PLUG
