water. A final wipe and rinse should be done with clean water only to remove any loose particles
and any soapy film residue.
Surface scratches, which have not exposed the metal substrate, can be lightly buffed or sanded
with 0000 steel wool or no. 400 sand paper to create a smoother surface. Care must be taken
to not expose the substrate under the paint. Once the substrate is exposed, the likelihood for
rusting is greatly increased.
If substrate is exposed, it must be treated to prevent rust from forming. Sand the exposed area
lightly and paint with a high quality metal primer specifically intended for galvanized surfaces
to protect the area from corrosion. Allow for drying time on primer can label before applying
topcoat.
The surface of the factory-applied finish, that is being painted, must not be too smooth, or the
paint will not adhere to it. It is advisable to test in an inconspicuous area, to evaluate adhesion.
If poor adhesion is observed, surface preparation for painting the factory-applied finish must
be repeated until desired results are achieved. Again, care must be taken to not expose the
substrate under the paint.
PAINTING
After surface has been properly prepared, it must be allowed to dry thoroughly, and then coated
immediately with premium quality latex house paint. follow paint label directions explicitly. Oil
base or solvent base paints are not recommended. Please note that if substrate is exposed and
not properly primed, painting with latex paint may cause accelerated rusting of the steel in the
exposed area.
NOTEs:
1. Re-painting of finish painted steel doors cannot be warranted, as this condition is totally
beyond the door manufacturer’s control.
2. Consult a professional coatings contractor if in doubt about any of the above directions.
3. follow directions explicitly on the paint container labels for proper applications of coatings and
disposal of containers. Pay particular attention to acceptable weather and temperature condi-
tions in which to paint.
Operation and Maintenance
OPERATING yOuR GARAGE DOOR…
Before you begin, read all warning labels affixed to the door and the installation instructions and
owner’s manual. When correctly installed, your Wayne-Dalton door will operate smoothly. Always
operate your door with controlled movements. Do not slam your door or throw your door into the
open position, this may cause damage to the door or its components. If your door has an electric
opener, refer to the owner’s manual to disconnect the opener before performing manual door
operation below.
Manual door operation:
for additional information on manual garage door operations go to
www.dasma.com and
reference TDS 165.
IMPORTANT: DO nOT PlACE fInGERS OR HAnDS InTO SECTIOn jOInTS WHEn OPEnInG
AnD/OR ClOSInG A DOOR. AlWAYS uSE lIfT HAnDlES/ SuITABlE GRIPPInG POInTS WHEn
OPERATInG THE DOOR MAnuAllY.
Opening a Door: Make sure the lock(s) are in the unlocked position. lift the door by using the lift
handles/ suitable gripping points only. Door should open with little resistance.
Closing a Door: from inside the garage, pull door downward using lift handles/ gripping point
only or a high friction area only. If you are unable to reach the lift handles/ suitable gripping
points only, use pull rope affixed to the side of door. Door should close completely with little
resistance.
using an electric opener:
IMPORTANT: Pull ROPES MuST BE REMOVED AnD lOCKS MuST BE REMOVED OR MADE
InOPERATIVE In THE unlOCKED POSITIOn.
When connecting a trolley type garage door opener to this door, an opener and/or trolley bracket
must be securely attached to the top section of the door, along with any u-bars provided with
the door. Always use the opener and/or trolley bracket supplied with the door. To avoid possible
damage to your door, Wayne-Dalton recommends reinforcing the top section on models 8000,
8100, 8200 and 9100 doors with a u-bar (may or may not be supplied). The installation of the
opener must be according to manufacturer’s instructions and force settings must be adjusted
properly. Refer to the owner’s manual supplied with your electric opener for complete details on
installation, operation, maintenance and testing of the opener.
MAINTAINING yOuR GARAGE DOOR…
Before you begin, read all warning labels affixed to the door and the installation instructions and
owner’s manual. Perform routine maintenance steps once a month, and have the door profes-
sionally inspected once a year. Review your Installation Instructions and Owner’s Manual for the
garage door. These instructions are available at no charge from Wayne-Dalton Corp., P.O. Box
67, Mt. Hope, Oh 44660, or at www.wayne-dalton.com. for additional information on garage
door/opener maintenance go to www.dasma.com and reference TDS 151, 167 and 179.
Monthly Inspections:
1. visual Inspection: Closely inspect jambs, header and mounting surface. Any wood found
not to be structurally sound must be replaced. Inspect the springs, cables, rollers, pulleys, back
hangs and other door hardware for signs of worn or broken parts. Tighten any loose screws
and/or bolts. Check exterior surface of the door sections for any minor cracks. Verify door has
not shifted right and/or left in the opening. If you suspect problems, have a trained door system
technician make the repairs.
WARNING WARNING
GARAGE DOOR sPRINGs, CABLEs, BRACkETs, AND OThER hARDWARE AT-
TAChED TO ThE sPRINGs ARE uNDER ExTREME TENsION, AND If hANDLED
IMPROPERLy, CAN CAusE sEvERE OR fATAL INjuRy. ONLy A TRAINED DOOR
sysTEMs TEChNICIAN shOuLD ADjusT ThEM, By CAREfuLLy fOLLOWING
ThE MANufACTuRER’s INsTRuCTIONs.
WARNING WARNING
NEvER REMOvE, ADjusT, OR LOOsEN ThE BOLTs, sCREWs AND/OR LAG
sCREWs ON ThE COuNTERBALANCE (END OR CENTER BEARING BRACkETs)
sysTEM OR BOTTOM BRACkETs Of ThE DOOR. ThEsE BRACkETs ARE CON-
NECTED TO ThE sPRING(s) AND ARE uNDER ExTREME TENsION. TO AvOID
POssIBLE sEvERE OR fATAL INjuRy, hAvE ANy suCh WORk PERfORMED By
A TRAINED DOOR
sysTEMs TEChNICIAN usING PROPER TOOLs AND INsTRuCTIONs.
Torquemaster ® Plus Springs: Pawl knob(s) (located on the TorqueMaster ® end brackets above
the door) should be engaged to prevent the door from rapidly descending in case of spring
failure or forceful manual operation.
Torsion Springs: The torsion springs (located above the door) should only be adjusted by a
trained door systems technician. DO nOT attempt to repair or adjust torsion springs yourself.
Extension Springs: A restraining cable or other device should be installed on the extension spring
(located above the horizontal tracks) to help contain the spring if it breaks.
2. Door Balance: Periodically test the balance of your door. If you have a garage door opener,
use the release mechanism so you can operate the door by hand when doing this test. Start with
the door in the fully closed position. lift the door to check its balance. Adjust Torquemaster ® or
Extension spring(s), if door lifts by itself (hard to pull down) or if door is difficult to lift (easy to
pull down). DO nOT attempt to repair or adjust Torsion Springs yourself. To adjust Torquemaster ®
or Extension spring(s), refer to your installation instructions and owner’s manual. If in question
about any of the procedures, do not perform the work. Instead, have it adjusted by a trained door
systems technician.
3. Lubrication: The door should open and close smoothly. Ensure the door rollers are rotating
freely when opening and closing the door. If rollers do not rotate freely, clean the door tracks, re-
moving dirt and any foreign substances. Clean and lubricate (use a non-silicon based lubricant)
hinges, steel rollers and bearings. DO nOT lubricate plastic idler bearings, nylon rollers, door
track. DO nOT oil a cylinder lock, if actuation is difficult use a graphite dust to lubricate.
WarranTy
Lifetime Limited Warranty
Models 9100, 9400, 9600
Subject to the terms and conditions contained in this lifetime limited Warranty, Wayne-
Dalton Corp. (“Manufacturer”) warrants the sections of the door, which is described at the top of
this page, for as long as you own the door against:
The door becoming inoperable due to rust-through of the steel skin from the core of i)
the door section, due to cracking, splitting, or other deterioration of the steel skin, or
due to structural failure caused by separation or degradation of the foam insulation.
Peeling of the original paint on the door as a result of a defect in the original paint or ii)
in the application of the original paint coating, in cases where the door sections and
the original paint: (a) have not been subjected to adverse atmospheric conditions or
contaminates (such as salt water or other marine environment, or to toxic or abrasive
substances, including those in the air); (b) have been maintained in compliance with
Manufacturer’s recommendations; and (c) have not been subject to physical abra-
sion, impacted by a hard object, or punctured (including without limitation “paint rub”
occurring in metal to metal contact and movement).
The Manufacturer warrants the garage door hardware (except springs) and the tracks of
the above-described door, for as long as you own the door, against defects in material and
workmanship, subject to all the terms and conditions below.
The Manufacturer warrants those component parts of the door not covered by the pre-
ceding provisions of this lifetime limited Warranty against defects in material and workmanship
for a period of ONE (1) yEAR from the date of installation.
The Manufacturer warrants the factory-applied finish and the factory attached stiles
against fading and cosmetic changes from the time of installation for TWO (2) yEARs. If the
door is re-stained or re-painted, the TWO (2) yEARs warranty for the factory-applied finish is
void. The Model 9400 factory attached stiles are warranted against peeling, cracking, chalking,
or delamination from the time of installation for TWO (2) yEARs.
After a period of TWENTy (20) yEARs, from time of installation, replacement of
lifetime limited Warranty materials will be pro-rated at 50 per cent of Manufacturer’s published
list pricing at time of claim, and you must pay this amount.
This limited Warranty is extended only to the person who purchased the product
and continues to own the premises (where the door is installed) as his/her primary residence
(“Buyer”). This limited Warranty does not apply to residences other than primary, or to commer-
cial or industrial installations, or to installations on rental property (even when used by a tenant
as a residence). This limited Warranty is not transferable to any other person (even when the
premises is sold), nor does it extend benefits to any other person. As a result this warranty does
nOT apply to any person who purchases this product from someone other than an authorized
Wayne-Dalton dealer or distributor.
The Manufacturer will not be responsible for any damage attributable to improper stor-
8
