TECHNICAL SPECIFICATIONS
86037580 GLIDE 01/03/07
3-1
ITEM DIMENSION/CAPACITY
Nominal power
2.9 kW
Rated Voltage 36 Volts DC
Rated Amperage 80 amps (28in & 32in)
95 amps (36in)
Batteries 6 x 6 Volt 250-335 AH @20 hr. rate
Scrub Brush Motors 2 x 1.0 HP (746 W) 28in & 32in
3 x 1.0 HP (746 W) 36in
Vacuum Motor(s) 1 x .75 HP (560 W) Standard, second motor
optional
Propelling Motor 1.3 HP (932 W)
Mass (GVW) 1810 lbs (820 kg) 28in & 32in
1840 lbs (835kg) 36in
Weight empty without batteries 790 lbs (360 kg) 28in & 32in
825 lbs (375 kg) 36in
Solution Control Gravity feed, fully variable with automatic shut
off in neutral
Solution tank capacity 30 gal (115 L)
Recovery tank capacity 30 gal (115 L)
Scrub brush diameter for 28 in. (71 cm) disk scrub head 14 inch (35.5 cm)
Scrub brush diameter for 32 in. (81 cm) disk scrub head 16 inch (40.6 cm)
Scrub brush diameter for 36 in. (91 cm) disk scrub head 12 inch (30.5 cm)
Scrub brush pressure 0-225 lbs (0-1000N) 28in & 32in
0-150 lbs (0-667N) 36in
Scrub brush speed 300 rpm
Tires 12 in. (30.5 cm) Solid Scrubber Compound
Foundation Pressure 108 lbs./in² (745 kPa)
Maximum Speed 4.1 miles/hour (6.5 Km/hour)
Coverage with 28 in. (71 cm) scrub head 42,328 ft²/hr @ 3.7 mph with 2 in. overlap
Coverage with 32 in. (81 cm) scrub head 48,840 ft²/hr @ 3.7 mph with 2 in. overlap
Coverage with 36 in. (91 cm) scrub head 55,352 ft²/hr @ 3.7 mph with 2 in. overlap
Frame Construction Powder coated steel
Brakes Self centering mechanical 7 in. (17.7 cm) disc
with hand lock parking brake
Minimum aisle u-turn width with 28 in. (71 cm), 32 in. (81 cm) or
36 in. (91 cm) disk scrub head 66 inches (168 cm)
Maximum rated climb and descent angle 7.5 degrees
