WM 550-141-996/1105

Page 19

RWB 6104WMNX R1005

Item

Description

Part No.

1

Head/Air adjustment mecha-

nism assembly

51794U

2

Air guide

101101U

3

Gasket, mounting fl ange (not

shown)

32389

4

Air tube combination,
(Includes Screws, air tube

mounting #8 x 3/8)

Specify
4396

5

Blower wheel

2999U

6

Connector tube assembly, 11”

51127

7

Coupling

2454

8

Door, rear access

32119U

9

Electrode insulator kit

51811U

10

CleanCut Fuel Pump,
(Requires Mounting Screws ¼

-20 x 7/8”)

2184404U
4189

11a

Gasket, igniter baseplate

51942U

11b

Gasket, igniter baseplate hinge 51942U

11c

Gasket, wiring

51942U

11d

Gasket, rear access door

51942U

15

Igniter, electronic

51771U

16

Inlet air box

1010U

17

Inlet air louvers

1013U

19

Nozzle Line Electrode and

Head Assembly

Specify

20

PSC Motor,
(Requires Mounting screws ¼

-20 x 7/8”)

21805U
4189

21

Primary control
R7184P Valve-on/Motor Delay
R7184P With Alarm Contacts

7457U
7458U

22

Retention head assembly,
6 -slot

51785U

23

Retention head assembly,
9 -slot

51815U

24

Splined nut

3666

25

Spring, igniter prop

32058U

26

Electrical box

5770

28

Cover, burner

32395U

29

Mounting plate, burner cover

32399U

30

Thumbscrews, cover mounting

21899U

31*

Pressure Switch Kit, including

switch, (2) hoses & pressure
switch/cad cell lead

21895U

32*

Air adapter w/Pressure Port &

Trim Plate

5199OU

33*

Parts kit, Including (2) hoses &

pressure switch/cad cell lead

51988U


* Denotes an optional part per burner specifi cation.

Part Number designations for Replacement Parts Dia-

grams on Page 18.

For best performance specify genuine

Beckett

replacement parts

Professional Maintenance
