Page 17: Remote control operation, En-14
EN-14
Installation
Connecting the Projector
USB Cable
VGA (D-Sub) to HDTV (RCA) Cable
VGA Cable (D-Sub to D-Sub)
Composite Video Cable
RS-232 Cable
S-Video Cable
Audio Cable
1
5
2
6
3
7
4
2
2
1
4
Desktop type
Laptop type
2
3
5
5
6
7
4
WPG-350
4
When connecting cable, power cords of both projector and external equipment
should be disconnected from AC outlet.
The figure above is a sample connection. This does not mean that all of these
devices can or must be connected simultaneously.
The cables that come with the projector may differ from the above illustration.
The included cables are based on actual shipment delivery.
