– 7 –
OUTPUT RELAYS/POWERLINE CARRIER DEVICES WORKSHEET FOR
*
80, and
*
81.
Applicable only if Relays and/or Powerline Carrier Devicess are to be used.
* 80 OUTPUT DEVICES – This is an interactive menu mode. Fill in the required data on the worksheet on below and follow
the programming procedure in the installation manual as you enter the data during the displays and prompts that appear
in sequence.
Notes: 1. For Relays, field * 25 must be programmed for a 4229 (Relays 01 and 02), OR for a 4204 (Relays 01 to 04).
2. For Powerline Carrier devices, field * 27 must be programmed with a House Code.
3 . Tampers of expansion units cannot be used to operate devices.
S T A R T
= either or both -
S T O P
КККККККККККК = either or both -
DEVICE
NUMBER
ACTION
(A)
ZONE
EVENT LIST
(EV) (ZL)
ZONE TYPEÊÊPART'N
SYST OP'N
No.
ККККК(ZT) (P)
RESTORE of
ZONE LIST
(ZL)
ZONE TYPEÊÊÊÊPART'N
/SYST OP'N
No.
(ZT) (P)
X-10
SELECT
OUTPUT RELAY
OR P.L.C.D.*
01
OUTPUT RELAY
OR P.L.C.D.*
Ê02
OUTPUT RELAY
OR P.L.C.D.*
К К03
OUTPUT RELAY
OR P.L.C.D.*
ÊÊ04
P.L.C.D.* КККККККК05
P.L.C.D.* КККККККК06
P.L.C.D.* КККККККК07
P.L.C.D.* ККККК КК08
+
* P.L.C.D. = Powerline Carrier Device (X-10).
Where:
X-10 SELECT = Powerline Carrier Device Enter “1” if Powerline Carrier Device is being used, enter “0” if relay is being used.
A = DEVICE ACTION 0 = No Response; 1 = Close for 2 sec; 2 = Close and stay closed; 3 = Pulse on and off.
EV Ê = EVENT 0 = Not used; 1 = Alarm; 2 = Fault; 3 = Trouble.
Z L = ZONE LIST 1, 2, or 3 (from Field * 81) or 0 = Not Used.
"START" ZONE LIST: Upon alarm, fault, or trouble of ANY zone on this list, device action will START.
"STOP"
RESTORE of ZONE LIST: Upon restore of ALL zones on this list, device action will STOP. It
need not be same list as used for START.
NOTE: Do not use input type "BR" transmitters in a zone list to STOP a relay action, since these
transmitters do not send restores.
ZT = ZONE TYPE/SYSTEM OPERATION
Choices for Zone Types are:
00 = Not Used 06 = 24 Hr Silent
01 = Entry/Exit#1 07 = 24 Hr Audible
02 = Entry/Exit#2 08 = 24 Hr Aux
03 = Perimeter 09 = Fire Trouble
04 = Interior Follower 10 = Interior w/Delay
05 = Trouble Day/Alarm Night 24= Silent Burglary
Note : Any zone in "ZT" going into alarm,
fault, or trouble will actuate relay.
Any zone of that type that restores
will stop relay action.
Choices for System Operation are:
20 = Arming–Stay 38 = Chime 52 = Kissoff
21 = Arming–Away 39 = Any Fire Alarm 58 = Duress
22 = Disarming (Code + OFF) 40 = Bypassing
31 = End of Exit Time 41 = **AC Power Failure
32 = Start of Entry Time 42 = **System Battery Low
33 = Any Burglary Alarm 43 = Communication Failure
36 = **At Bell Timeout***
** Use 0 (Any) for Partition No. (P) entry.
*** Or at Disarming, whichever occurs earlier.
Note: In normal operation mode:
Code + # + 7 + N Key Entry starts Device N.
Code + # + 8 + N Key Entry stops Device N.
P = PARTITION No.ÊÊ 1, 2, or 0 for Any
