TO PROGRAM SYSTEM STATUS, & RESTORE
REPORT CODES (

59Ð

76, &

89):

With a 3+1 or 4+1 Standard Format:

Enter a code in the

first

box: 1–9, 0, B, C, D, E, or F. Enter "#+10" for 0, "#+11" for B,
"#+12" for C, "#+13" for D, "#+14" for E, "#+15" for F.

A "0" (

not "#+10") in the first box will disable a report.

A "0" (

not "#+10") in the second box will result in auto matic

advance to the next field when programming.

With an Expanded or 4+2 Format:

Enter codes in

both boxes

(1st and 2nd digits) for 1–9, 0, or B–F, as de scribed above.

A "0" (

not "#+10") in the second box will eliminate the ex-

panded message for that report.

A "0" (

not "#+10") in both boxes will disable the report.

With Ademco Contact ID Reporting:

Enter any digit (other

than "0") in the

first box, to enable zone to report (entries in the

second boxes will be ignored).

A "0" (

not "#+10") in the first box will disable the report.

Examples:

For Code

(single digit), enter: 3 | 0

For Code

3 2

(two digits), enter: 3 | 2

For Code

B 2

(Hexadecimal), enter: #+11 | 2

SYSTEM STATUS REPORT CODES (

59–

68)

Default for all report codes = [00]

EXIT ERROR REPORT CODE

TROUBLE REPORT CODE

BYPASS REPORT CODE

AC LOSS REPORT CODE

LOW BAT REPORT CODE

TEST REPORT CODE

OPEN REPORT CODE

Part. 1

††

Part. 2

††

ARM AWAY/STAY RPT CODE

Part. 1

††

AWAY STAY

Part. 2

††

AWAY STAY

† 2nd digit is automatically sent as the 2nd digit of the
zone alarm report code programmed in

56, if

expanded or 4+2 report ing is selected.

†† 2nd digit is automatically sent as the user number if

expanded or 4+2 reporting is selected.

RF XMTR LOW BAT REPORT CODE

CANCEL REPORT CODE

RESTORE REPORT CODES (

70–

76)

Default for all restore report codes = [00]

ALARM RESTORE RPT CODE

2nd digit is automatically sent as the 2nd digit of
the zone alarm report code programmed in

56, if

expanded or 4+2 re porting is selected.

TROUBLE RESTORE RPT CODE

BYPASS RESTORE RPT CODE

AC RESTORE RPT CODE

LOW BAT RESTORE RPT CODE

Reports with Partition 1 Subscriber No.

RF XMTR LO BAT RST RPT CODE

TEST RESTORE RPT CODE

OUTPUT AND SYSTEM SETUP (

80–

93)

OUTPUT RELAYS AND
POWERLINE CARRIER
DEVICES

ZONE LISTS FOR OUTPUT
DEVICES

Program only if
Relays and/or
Powerline Carrier
devices are to be
used. See next page.

CUSTOM ALPHA EDITING:

(Also entered from field

56):

See procedure in instructions.

SEQUENTIAL LEARN MODE

(Also entered from

field

56):

See procedure in instructions.

EVENT LOG 80% FULL RPT CODE

EVENT LOGGING

[3]

0 = None; 1 = Alarm/Alarm Restore;
2 = Trouble/Trouble Restore; 4 = Bypass/Bypass
Restore; 8 = Open/Close.
Example: To select “Alarm/Alarm Restore”, and
“Open/Close”, enter 9 (1 + 8); To select all, enter #15.

Note:

System messages are logged when any non-

zero selection is made.

OPTION SELECTION (AAV)

[0]

0 = None; 4 = AAV;“0” for UL installations.

PHONE LINE MONITOR ENABLE

[0]

0 = Not used
1 = Keypad display when line is faulted
2 = Keypad display plus keypad trouble sound
3 = Same as “2”, plus Device #2 STARTS. If either
partition is armed, external sounder activates also.

Note:Ê

Device #2 must either be programmed to be

STOPPED in field

80 or STOPPED by Code + # + 8 + 2.

No. OF REPORTS IN ARMED PERIOD

[0]

0 = 10 Alarm/Alarm Restore Reports; 1 = Unlimited.
“1” for UL installations.

DOWNLOAD INFORMATION (

94,

95)

DOWNLOAD PHONE No.

| | | | | | | | | | | | | | |

Enter up to 16 digits, 0–9;

#+11 for '*'; #+12 for '#'; #+13 for

a pause. Do not fill unused spaces. If fewer than 16 digits
entered, exit field by pressing

(and press 95, if entering

next field). To clear entries from field, press

Note:

In UL installations, down loading may only be

performed if a technician is at the site.

RING DET COUNT FOR DOWNLOADING[0]

0 = Disable Station Initiated Download; 1–14 = number
of rings (1–9, # +10 =10, # +11 =11, # +12 =12,
# +13 =13, # +14 =14); 15 = answering machine defeat
(# +15 =15)

Note:

Do not enter “0” if using 4285 Voice Module.

INITIALIZES DOWNLOAD ID, SUBSCRIBER
ACCOUNT No. FOR INITIAL DOWNLOAD:

No data entry required.

SETS ALL PROGRAM FIELDS TO DEFAULT
VALUES:

No data entry required.

Exits programming mode and

prevents re-entry

by: Installer Code + 8+ 0 + 0. If

is used to

exit programming mode, system must be
powered down, and method 1 above used to
enter the programming mode.

Exits programming mode and

allows re-entry

by: Installer Code + 8 + 0 + 0 or: Power-up, then
press "

" and "#" within 50 seconds of power up.
