– 2 –

Local programming requires the use of a 2-line Alpha keypad connected to
partition 1 keypad terminals on the control.

NOTE: For UL installations, the system may be configured as a single partition only.

Field

Function

Programmed Values

[ ]

= Default Value

SYSTEM SETUP (*20–*29)
*

20

INSTALLER CODE

| | | [4 1 1 2]

Enter 4 digits, 0–9

*

21

QUICK ARM ENABLE

[0]

Part. 1

†

Part.2

†

0 = no; 1 = yes

*

22

RF SYSTEM

[0]

0 = none; 1 = 5800 (5881/5882)

*

23

FORCED BYPASS

[0] [0]

Part. 1

†

Part. 2

†

0 = none; 1 = bypass open zones

“0”. for UL installations.

*

24

RF HOUSE ID CODE

| [0][0]

00 = disable all wireless keypad usage; 01–31 = using 5827
keypad; Partition 2 RF House ID = Partition 1 House ID +1

*

25

WIRED ZONE EXPANSION

† [0]

0 = none; 1 = 4219; 2 = 4229; 3 = 4204

*

26

CHIME BY ZONE

† [0]

0 = no; 1 = yes (program zones to chime on zone list 3)

*

27

X–10 HOUSE CODE

[0]

0 = A; 1 = B, 2 = C, 3 = D, 4 = E, 5 = F, 6 = G, 7 = H, 8 = I, 9 =
J, #10 = K, #11 = L, #12 = M, #13 = N, #14 = O, #15 = P

*

28

PHONE MODULE ACCESS CODE

| [00]

(Partition 1 only) 1st digit: enter 1–9; 2nd digit: enter # + 11 for "*
", or # + 12 for "#". Entering 0 for either digit disables code.

*

29

OUTPUT TO LONG RANGE RADIO

[0]

0 = disable; enable = Trouble code 1–9, B (# +11), C (# + 12), D
(# + 13), E (# + 14), or F (# + 15). The 2nd digit of Trouble Dialer
Report is automatically entered from field * 60. “0” for UL
installations.

ZONE SOUNDS AND TIMING (*31–*39)
*

31

SINGLE ALARM SOUNDING/ZONE

† [0]

1 = yes; 0 = no; “0” for UL installations.

*

32

FIRE SOUNDER TIMEOUT

† [0]

0 = timeout; 1 = no timeout

*

33

ALARM BELL TIMEOUT

† [1]

0 = none; 1=4 min; 2=8 min; 3=12 min; 4 = 16 min; “1” (4 min.)
minimum for UL.

*

34

EXIT DELAY

|

| [70] [70]

Part. 1†

Part. 2†

00-99 = exit delay time for each partition

*

35

ENTRY DELAY 1 (zone type 01)

| | [30] [30]

Part. 1 † Part. 2 †

00-99 = entry delay 1 time for each

partition; 20 seconds max. for UL installations

† Entry of a number other than one specified will give unpredictable results.
