Operation
Vision Model 140/150 Installation/Operation Manual 65
PRE
L
IMINAR
Y
Main Menu The Main Menu is the starting point for accessing all projector functions.
(The Calibration and Service menus are hidden and not accessible until you enter a
passcode.)
Input Source From the Main Menu, select Input Source to choose a video signal source.
The active source is indicated by an arrow (>) to its left; in this example, Composite is the
active source.
Aspect Ratio To change the aspect ratio (size and shape) of the projected image, select Aspect Ratio from
the Main Menu and press ENTER. Select the appropriate aspect ratio for your screen size and
the type of program material being viewed; refer to Table 4-1.
The currently-selected aspect ratio is indicated by a “
7
” to its left; in this example, 16:9 is
selected.
Vidikron Video
Input Source
Aspect Ratio
Input Position
ISF Presets
Information
Calibration
Service
Input Source
> Composite
S-Video 1
S-Video 2
Component SD
HD/RGB 1
HD/RGB 2
HDMI 1
HDMI 2
Aspect Ratio
7
16:9
4:3
Letterbox
IntelliWide
Cinema
Intelliwide 2.35
The aspect ratio selection is automatically saved for each input and
resolution.
Note
