Installation
34 Vision Model 140/150 Installation/Operation Manual
PRE
L
IMINAR
Y
Composite/S-Video/Component Video Connections: See Figure 3-13.
Figure 3-13. Composite, S-Video and Component Video Connections
HD1
HD2
G/Y
INPUTS
H V R/Pr B/Pb
G/Y H V R/Pr B/Pb
Component Video
Pb Pr Y Video S-Video 2
S-Video 1
1 2 3
TRIGGERS
HDMI 1 HDMI 2
DVD Player, VCR,
Satellite Receiver,
Laser Disc etc.
Pb Pr Y
