Optional Accessories
> Replacement Lamp
RLC-059
> Universal Ceiling Mount Kit
WMK-005
> Wireless G Presentation Gateway
WPG-360
> USB Wireless Adapter (802.11 b/g/n) WPD-100
> Extended Express Exchange
®
PRJ-EE-08-03
Sales: (888) 881-8781 . [email protected] . ViewSonic.com
*Running eco-mode exclusively can extend lamp life. See ViewSonic.com for full Express Exchange
®
details. Programs, specifications and availability are subject
to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. DLP
®
and the DLP logo
are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. HDMI, the HDMI Logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. Corporate names, trademarks stated herein
are the property of their respective companies. Copyright © 2012 ViewSonic Corporation. All rights reserved [16347-00B-08/12] Pro8400-1
Projection
Distance
4:3 Aspect
M
1.5
1.8
2
3
5
10
DISPLAY
Type
0.65" Digital Micromirror Device (DLP
™
)
Resolution
1920x1080 (1080p)
Lens
1.5× Manual optical zoom / Manual optical focus
Keystone
Vertical digital keystone correction: +/– 20 degrees
Size
30"–300" / 0.76m–7.6m
Throw Distance
0.9m–10m / 3ft–32.8ft
Throw Ratio
1.4 – 2.14:1
Lamp
280 watt
Lamp Life (Normal / Eco-mode) 4000 / 5000* hours
Brightness
4000 Lumens
Contrast Ratio
2600:1 (typ), 3000:1 (dynamic)
Aspect Ratio
16:9 (native) and 4:3
Color Gamut
70% NTSC 1931 CIE
INPUT SIGNAL
Computer and Video
NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N,
60), SECAM (B, D, G, K, K1, L), SD 480i and 576i (24fps,
25fps and 30fps), ED 480p and 576p (24fps, 25fps and
30fps), HD 720p, 1080i and 1080p (24fps, 25pfs and 30fps)
Frequency
Fh: 31–91KHz, Fv: 48–85Hz
COMPATIBILITY
PC
VGA to 1080p
Mac
®
Up to 1080p
CONNECTOR
RGB Input
15-pin mini D-sub (x2)
RGB Output
15-pin mini D-sub
Digital Input
HDMI 1.3 (x2)
Component
RCA (x3)
Composite Input
RCA jack
S-video Input
4-pin mini-DIN
USB
Mini-B for direct presentation from computer
Type A supports JPEG, BMP, TIFF, PNG, GIF from USB flash drive
Audio Input
3.5mm mini jack
Audio Output
3.5mm mini jack
Control
RS-232 (DB-9)
Network RJ-45
Screen Trigger
0.35 plug (12V/1A)
AUDIO
Speaker
10W (x2)
POWER
Voltage
100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption
360W (max) / <1W (stand-by mode)
CONTROLS
Basic
Power, keystone/arrow keys, left/blank, menu/exit,
right/panel key lock, auto, mode/enter, source
OSD
Picture: Brightness, Contrast, Color Setting, Keystone,
Aspect Ratio, Image, White Intensity, Gamma
Computer Image: Frequency, Tracking, H Position, V Position
Video Image: Saturation, Sharpnes, Tint
Setting: Menu Position, Projection, Signal Type, Lamp
Hour, Lamp Hour Reset, Filter Mode, Filter Hours, Filter
Hours Reset, Power Saving, Auto Source, Eco-mode, High
Altitude, OSD Timeout
Advance: Blank Screen, Password Word, Screen Capture,
Start up Screen, Digital Zoom, DCR, Close Captions
OPERATING
Temperature
32ºF–104ºF (0ºC–40ºC)
CONDITIONS
Humidity
10%–90% (non-condensing)
Altitude
0~6,000 ft (1,800m), operational up to 10,000 ft (3048m)
NOISE LEVEL
Normal / Eco-mode
33dB / 29dB
DIMENSIONS
Physical
13.1 Ч 4.8 Ч 10.4 (in) / 332.7Ч 121.9 Ч 264.2 (mm)
(W x H x D)
Packaging
16.3 Ч 7.5 Ч 14.8 (in) / 414 Ч190.5 Ч 375.9 (mm)
WEIGHT
Net
8.5 lb (3.86 kg)
Gross
11.8 lb (5.36 kg)
REGULATIONS
CB, RoHS, SVHC, WEEE, UL/cUL, FCC-B, ICES-004, TUV-S
(Argentina), NOM, PSB, C-tick, KC, CE, GOST-R, Hygienic,
UKrSEPRO, CCC
PACKAGE CONTENTS
ViewSonic projector, power cable, VGA cable, HDMI cable,
remote control/laser with batteries, lens cap, Quick Start
Guide, ViewSonic Wizard DVD (with User Guide), soft
carrying case.
WARRANTY
3-year limited warranty on parts, 1-year limited warranty
on lamp, 1st year Express Exchange
®
service.
For more product information, visit us on the web at ViewSonic.com
Pro8400
HIGH BRIGHTNESS 1080P PROJECTOR – PROFESSIONAL GRADE INSTALLATION
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
Feet
4.92
5.90
6.56
9.84
16.40
32.80
Wide
Tele
Inches
47.8
57.4
63.7
95.8
159.5
319.0
Inches
31.8
38.1
42.4
63.7
106.0
212.1
M
1.22
1.49
1.62
2.44
4.05
8.11
M
0.81
0.97
1.08
1.61
2.69
5.39
