Classification Function Dial operation Number Description
Paging
Data
Transmitting
and
Receiving Unit
All-call plus 7-zone paging
All-call plus 15-zone paging
Combination paging
All-call response
Zone paging response
Paging transfer
In/Out annunciation
One-shot make output
Make/break output
8-selectable output
(Decimal output)
4 decimal digits output
Make output for Pager control
Pocket Pager response
Clearing calling party indication
Conversation Paging
Transfer
Conversation after response
original station
Personal number registration/cancellation operation
— lamp on/off
(Make)
(Break)
Unit no. Condition no.
Unit no. Condition no.
Unit no. 4-digits
00 (All-call),
Y Y Y Y 0000-9999
Any station can be used to initiate PA or
station paging. A person paged can respond
from the nearest master station.
Several zones may be paged simultaneously.
Response to all-call
Response to zone paging or combination
paging.
This function allows a called parts to transfer
the call to a third party who responds to paging
The in/out annunciation can be controlled from
any master station.
One-shot make output of relay may control
other equipments such as ITV camera, VTR
control, dectating systems, etc.
Make/break output of relay may control other
equipments.
8 selectable outputs or a decimal output is
available (indicating room status and
destination).
4 decimal digits output is indicated.
Control the pocket pager by make output of
relays.
This is used to cancel the calling party indica-
tion without conversation.
Conversation with
0 (All-call) 1 ~ 7 (Zone)
0 1 ~ 15 (Zone)
0 ~ 9 (Combination)
0 ~7 (00-15)
90 ~ 99
000 ~ 499
000 ~ 511
1 ~ 9 Y 0 ~ 7
(0 ~ 9 )
01~64 Y 0 ~ 7
(01~99) (0 ~ 9 )
1 ~ 9
000~239
—
4
—
