E3100/3200
Assembly
Step 3 • Seat and Seat Post
1: Slide the Seat Post (65) through the Rubber Seat Post Cover (84) and
into the frame Seat Post receiver tube. The Seat Post numbers should
be facing the right or Seat Pin side of the Fitness Cycle. Be sure to
liberally grease the threads on the Seat Clamp Bolt.
2: Attach the Seat (108) to the Seat Post (65).
NOTE: These Seat Clamp nuts should be tightened alternately
(see illustration);
A: First snug one nut, then the other.
B: Partially tighten one nut, then the other.
C: Finally, fully tighten one nut, then the other.
DO NOT TIGHTEN ONLY ONE SIDE.
3: To avoid scratching the Seat Post paint, always hold the Seat Pin Knob
out when adjusting the Seat Post height. Turn the inner knob
clockwise to lock in place.
C:
D:
A:
B:
W Wrroonngg!!
