ViewSonic PJ500/PJ550/PJ501/PJ551 10
Basic Operation
Table 3 below refers to buttons on the projector control panel and on the remote control. Items
marked with (*) may be accessed from the projector control panel.
Table 3: Basic Operation
Item Description
INPUT SELECT
(projector control panel)
Select Input Signal (*) : press the INPUT Button.
RGB J VIDEO J S-VIDEO J COMPONENT (JRGB)
Select RGB Input: Press the RGB button.
VIDEO/S-VIDEO/COMPONENT J RGB
Select Video Input: Press the VIDEO button.
RGB J VIDEO/S-VIDEO/COMPONENT
VIDEO J S-VIDEO J COMPONENT (JVIDEO)
• The selected signal name is displayed for approximately 3 seconds when the input signal is
changed.
POSITION
(remote control)
Set/Clear Position Adjustment mode : Press the POSITION button.
“POSITION” is displayed in the POSITION mode.
Image Position Adjustment: Press the buttons in the POSITION mode.
• Valid only in the MAGNIFY mode when a video signal is input.
• After approximately 10 seconds of inactivity “POSITION” disappears and the POSITION
mode is cleared automatically.
RESET (*)
(remote control)
Initialize Each item: Select an item and press the RESET button.
Initialize Position Adjustment: Press the RESET button in the POSITION mode.
This function is valid only when RGB signal is input.
• Valid except for: VOLUME, LANGUAGE, H PHASE, and WHISPER.
MAGNIFY
(remote control)
Set MAGNIFY Mode: Press the MAGNIFY “ON” button.
Move Magnified Area: Run the POSITION in the MAGNIFY mode.
Adjust Magnification: Press the MAGNIFY / button in MAGNIFY mode.
MAGNIFY magnifies the image. MAGNIFY (-) reduces the image.
Clear MAGNIFY Mode: Press the MAGNIFY button.
• The MAGNIFY mode is cleared by selecting AUTO, ASPECT, INPUT SELECT, or VIDEO,
or changing the input signal.
FREEZE
(remote control)
Set/Clear FREEZE Mode: Press the FREEZE button. When the [ II ] icon is displayed, the
image is frozen in the FREEZE mode.
• The FREEZE mode is cleared by selecting POSITION, VOLUME, MUTE, Automatic
Adjustment, BLANK ON/OFF, or MENU ON/OFF, or by changing the input signal.
• Do not forget to clear frozen static images.
KEYSTONE (*)
(projector control panel
and remote control)
Set/Clear KEYSTONE Mode: Press the KEYSTONE button.
Adjust Keystone: Press the / buttons in the KEYSTONE mode.
reduces the width of the bottom of the projected image. reduces the width of the top
of the projected image.
VOLUME
(remote control)
Set/Clear VOLUME Mode: Press the VOLUME button to display the Volume menu, then
press
/ buttons on the remote control to increase/decrease the loudness of the
sound.
After the desired volume is selected, press the VOLUME button again to exit the Volume
mode.
MUTE
(remote control)
Set/Clear Mute Mode: Press the MUTE button. The sound is silenced in this mode.
